Introduction MXR-B3 series (also called MXR-SLC) based on MXR-B2 series (also called MXR-SNA) coilovers, which is also height adjustable but adds damping adjustment ability by a knob the top of the shaft. They are also made for street use, but the 24 level rebound damping control allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Application Compatible for Subaru Legacy Outback B4 BEE/BE5 1998.12-2003.05 Compatible for Subaru Legacy Outback TOURING WAGON BHE 1998.06-2003.05 Compatible for Subaru Legacy Outback TOURING WAGON BHE/BH5 1998.06-2003.05 Specification Quantity: 2 pieces front + 2 pieces rear Top mounts: Front-camber plates; rear-rubber top mounts Spring rate Front: 10kg/mm (448 lbs/in) Spring rate Rear: 7kg/mm (392 lbs/in) Adjustable Damper: 24 Ways adjustable Damper Adjustable

Height: Yes lowering 1" to 3" Shock type: Twin tube Spring preload: 7-10 mm
Colour: Golden body+black spring Dimension 71*51*21cm 27080g Feature 1. Damping adjustable ---24 ways damping force 2. Full length height adjustable---lower your car 1-3 incheds to get performance ride 3. Adjustable camber (for some models) 4. Independent Ride Height & Spring Pre-load Adjustments 5. Twin-Tube System for Comfortable Ride on Streets 6. Coated finish to avoid rust 7. Weight Saving Aluminum Components & heavy duty Steel Lower Mount Brackets 8. Simple install, Easy to adjust. Warranty: one year warranty for any manufacturing defect


...

Introduction MXR-B3 series (also called MXR-SLC) based on MXR-B2 series (also called MXR-SNA) coilovers, which is also height adjustable but adds damping adjustment ability by a knob the top of the shaft. They are also made for street use, but the 24 level rebound damping control allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Application Compatible for Lexus ES300 1997-2001 Exclude Adjustable Suspension compatible for Lexus ES300 1995-1996 ALL compatible for Lexus ES300 1992-1994 w/ Sealed Struts compatible for Toyota Avalon 1995-2003 ALL compatible for Toyota Camry 1995-2001 ALL compatible for Toyota Camry 1992-1994 ALL w/ Sealed Struts compatible for Toyota Solara 1999-2003 ALLSpecification Top mount: front camber plate; rear pillow ball Damping: 24 levels rebound damping adjustable Front spring rate:10 kg/mm (560 lbs/in) Rear spring rate:6 kg/mm (336 lbs/in) Adjustable

Height: Yes lowering 1" to 3" Spring Preload: 7-10 mm Shock type： Twin tube
Colour: gold body with black spring Package included Complete coilovers assembly 2 front & 2 rear A pair wrench for height adjustment Dimension Package dimension: 71*51*21 Weight: 31180g Feature 1. Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance. 2. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. 3. Camber plate top mounts help to eliminate the need for a separate camber kit. 4. Twin-Tube structure allows sufficient stroke within the shock absorber. 5. Complete Suspension Kit of 4 Shock Absorbers & 4 Springs for an easy installation. 6. Separate height adjustment does not affect damper stroke & height can be adjusted with coilovers installed on the vehicle. 7. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%. Plus the special surface treatment improves the durability & performance. 8. Most pieces in our coilover systems, including mounts, collars & spring perches, are designed from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust resistant components. 9. Steel shock bodies with special surface treatment to improve the durability. 10. Full rebuildable Warranty: one year warranty for any manufacturing defect




...

Application Compatible for Toyota Yaris Sedan / Vios 2013+ Specification Quantity: 2 pieces front + 2 pieces rear + 2 pieces spanner wrenches Damper: 24 Ways Adjustable Damper Front spring rate:6 kg/mm (336 in/lbs) Rear spring rate:N/A Height adjustable:YES Warranty: one year warranty for any manufacturing defect Feature * Adjustable ride height * Adjustable pre-load spring tension * Most components are made from 6061 aluminum with T6 for increased hardness -- the advantages include excellent strength, & aluminum helps keep the weight down. * Hi Tensile performance spring
- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. Plus, the special surface treatment is to improve the durability & performance. * All inserts come with fitted rubber boots to protect the damper & keep clean. * A fast & affordable way to easily upgrade your car's appearance. * Easy installation with right tools. Note* No instruction included; Professional installation & alignment suggested. * Please check our store for other auto parts you may be interested in. * Please feel free to contact us for whatever we can help
...

Introduction MXR-B2 series (also called MXR-SNA) coilovers are designed as an entry level for street use. It features with full length height adjustable & adjustable camber plates (applicable for some vehicles), which offers you a lowered stance, enhanced performancefor your daily use vehicle. Application Compatible for Subaru Legacy 2000-2004 BE sedan only Specification Top mounts: front
- pillow ball top mount with camber plate Rear
- standard rubber top mount Damping: non-adjustable Spring rate Front: 9 kg/mm (504 lbs/in) Spring rate Rear: 12 kg/mm (672 lbs/in) Spring length Front: 190mm Spring length Rear: 190mm Adjustable

Height: lowering 1-3inch Coilover overall length Front: 460mm-520mm Coilover overall length Rear: 400mm-450mm Shock type: Twin tube Spring Preload: 7-10 mm
Colour: golden Package includedcomplete coilovers 2 front & 2 rear a pair wrench for height adjustment Dimensionweight: 25820g

Size: 63*51*21 cm Feature 1. Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance 2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent 3. Adjustable Camber Plate & Pillow ball top mount for sharpening steering response. (for some models) 4. CNC machined Aluminumtop mounts & lockers--
- excellent strength, & save weight 5. Heavy Duty Steel Lower Mounts--- Highly Durable Reliable 6. High tensile spring---600, 000 times continuously test to assure it's high tensile strength. 7. All inserts come with fitted long rubber boots--- To protect the damper more well & be durable. 8. Twin-Tube structure ---provides excellent handling control characteristics for most driving conditions 9. Corrosion Finish
- Anodized Aluminum & Powder Coated Carbon Steel Parts Warranty: one year warranty for any manufacturing defect









...

Introduction MXR-B3 series (also called MXR-SLC) based on MXR-B2 series (also called MXR-SNA) coilovers, which is also height adjustable but adds damping adjustment ability by a knob the top of the shaft. They are also made for street use, but the 24 level rebound damping control allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Application Compatible for Subaru BRZ First generation (ZN6/ZC6) 2012-2020 compatible for Scion FR-S 2012-2020 compatible for Toyota 86 2012-2020 Specification Top mounts: Front pillow ball top mount Damping: 24 levels rebound damping adjustable Shock type: Twin tube Adjustable

Height: Yes, lowering 1'' to 3'' Adjustable camber plate: Yes Spring preload: 7-10 mm Spring rate Front: 6 kg/mm (336 lbs/in) Spring rate Rear: 5 kg/mm (280 lbs/in)
Colour: Golden Package includedproduct included: complete coilovers 2 front & 2 rear as shown in the picture Dimension
Size: 63*51*21 cm Weight: 21.24kg Feature Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Twin-Tube structure allows sufficient stroke within the shock absorber. Pillow ball top mount
- It improves the steering feel & response. Rubber top mounts help to deliver a smooth & forgiving ride for city use at any speed & rubber joints assist in absorbing hard impacts. Complete Suspension Kit of 4 Shock Absorbers & 4 Springs for an easy installation. Separate height adjustment does not affect damper stroke. Height can be adjusted with coilovers installed on the vehicle. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%. Plus the special surface treatment improves the durability & performance. Height Adjustment tools included. Full rebuildable. Warranty: one year warranty for any manufacturing defect






...

Introduction MXR-B3 series (also called MXR-SLC) based on MXR-B2 series (also called MXR-SNA) coilovers, which is also height adjustable but adds damping adjustment ability by a knob on the top of the shaft. They are also made for street use, but the 24 level rebound damping control allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Application Compatible for TOYOTA ALTEZZA AS200 1998.10-2005.07JPN GXE10 compatible for TOYOTA ALTEZZA RS200 1998.10-2005.07JPNSXE10 compatible for LEXUS IS300 2000-2005 USA JCE10L （INCL SPORTS CROSS (5DR) ） Compatible for LEXUS IS 200 1999.4
- 2005.7 GXE10（INCL SPORTS CROSS (5DR) ） Compatible for TOYOTA MARK II 2000.10-2004.11 JPN JZX110 GRANDE IR-V, GRANDE G-TB compatible for TOYOTA MARK II BLIT 2002.01-2007.05JPN JZX110W 2.5IR-V, 2.5IR-SSpecification Top mounts: rubber top mounts Damping: 24 levels rebound damping adjustable Spring rate: front 12kg/mm Spring rate: rear 10kg/mm Adjustable

Height: Yes lowering 1'' to 3'' Shock type: Twin tube Spring preload: 7-10 mm
Colour: gold Package includedcomplete coilovers 2 front & 2 rear a pair wrench for height adjustment Dimensionweight: 24940g

Size: 71*51*21 cm Feature 1. Lowered height adjustment from 1''-3'' which allow lower center of gravity & also add a more aggressive stance 2. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. 3. Rubber top mounts help to deliver a smooth & forgiving ride for city use at any speed & rubber joints assist in absorbing hard impacts. 4. Twin-Tube structure allows sufficient stroke within the shock absorber 5. Separate height adjustment does not affect damper stroke 6. High Tensile performance spring – STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%. Plus the special surface treatment improves the durability & performance. 7. Height Adjustment tools included 8. Most pieces in our Coilover systems, including mounts, collars & spring perches, are designed from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust resistant components. 9. Full rebuildable Warranty: one year warranty for any manufacturing defect





...

Introduction MXR-B3 series (also called MXR-SLC) based on MXR-B2 series (also called MXR-SNA) coilovers, which is also height adjustable but adds damping adjustment ability by a knob the top of the shaft. They are also made for street use, but the 24 level rebound damping control allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions. Application Compatible for Honda S2000 BASE MODEL/TYPE V AP1/AP2 2000-2009 Specification Top mounts: Standard rubber top mount front & rear Adjustable camber plate: No Damping: 24 ways damping adjustable Spring rate Front: 10 kg/mm (560 lbs/in) Spring rate Rear: 10 kg/mm (560 lbs/in) Spring length Front: 180mm Spring length Rear: 230mm Adjustable

Height: lowering 1-3 inch Coilover overall length Front: 430mm-480mm Coilover overall length Rear: 515mm-580mm Shock type: Twin tube Spring preload: 7-10 mm
Colour: Golden Package includedcomplete coilovers 2 front & 2 rear as shown in the picture Dimension
Size: 63*51*21 cm Weight: 21.98kg Feature 1. Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance 2.24 levels of adjustable damper -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff. 3. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent 4. Adjustable Camber Plate & Pillow ball top mount for sharpening steering response. (for some models) 5. CNC machined Aluminumtop mounts & lockers--
- excellent strength, & save weight 6. Heavy Duty Steel Lower Mounts--- Highly Durable & Reliable 7. High tensile spring---600, 000 times continuously test to assure it's high tensile strength. 8. All inserts come with fitted long rubber boots--- To protect the damper more well & be durable. 9. Twin-Tube structure ---provides excellent handling & control characteristics for most driving conditions 10. Corrosion Finish
- Anodized Aluminum & Powder Coated Carbon Steel Parts Warranty: one year warranty for any manufacturing defect






...

Introduction A coilover is an automobile suspension device. Thanks to built-in adjustability, coilovers offer the ability to be shortened or lengthened
- lowering or raising the ride height of your vehicle through manual adjustment, without complex electronics or hydraulics. A coilover kit consists of a damper & a shock absorber with a coil spring around it. Maxpeedingrods provides performance aftermarket adjustable coilovers suspension kit compatible for Toyota Corolla series. You can enjoy a comfortable riding experience in all road conditions. Application Compatible for Toyota Corolla E90 E100 E110 AE92 AE101 AE111 1988-1999 Notice: The coilovers kit will " Lower your car" & does not keep to the original ride height. Specification Top mount: Front camber plate；rear pillow ball Quantity: 4PCS of Coilovers (2 piece front + 2 pieces rear) Adjustable damper: 24 ways adjustable damper force Adjustable camber plate: Yes（front only） Adjustable

Height: lowering 1-3 inch Spring rate front: 8 kg/mm (448 lbs/in) Spring rate rear: 6 kg/mm (336 lbs/in) Shock type: Twin tube Spring preload: 7-10 mm
Colour: Gloden Warranty: 1 year warranty for any manufacturing defect Daily driver, occasional autocross day or occasional track days，equally at home on street & track. For those seeking a lowered stance as well as enhanced handling & response at a high value. Feature- Able to lower ride height by 1''-3''; allows user to have a more aggressive stance.- Coilovers are 24-way adjustable. Rebound & Dampening adjustment which allows the user the ability to dial in your coilovers to any driving needs. The user can enjoy a comfortable riding experience in all road conditions.- Pillow ball top mount --- this design helps combat noise while tuning. It also improves the steering feel & response.- Twin-Tube Shock design is used for low internal frictional resistance in order to increase efficiency & keep shock temps low.- Height adjustment does not sacrifice damper stroke length.- These coilovers are able to have their height adjusted without being taken out of the car.- High Tensile strength performance spring---Tested under a 600, 000 time continuous compression test, the spring distortion was less than 0.04%. Plus, the special surface treatment improves the durability & performance.- Adjustment tools included in the kit. Notice- No instruction included; Professional installation & alignment suggested.- Please check our store for other auto parts you may be interested in.- Please feel free to contact us for whatever we can help.



...

Application Compatible for Toyota Corolla 9th Gen. (E130) 2003-2008 USA Compatible for Toyota Corolla 9th Gen (_E12_) (01/2001-12/2007) other markets Compatible for Toyota Matrix XRS (E130) 2003-2008 Notice: The coilovers kit will " Lower your car" & does not keep to the original ride height. Specification Product included: 4PCS of Coilovers (2 piece front + 2 pieces rear) Adjustable damper: 24 ways adjustable damper force Spring rate front: 12kg/mm (672 lbs/in) Spring rate rear: 8 kg/mm (448 lbs/in) Height adjustable: Front: 347-457mm; Rear: 445-490mm Shock type: Twin tube Spring preload: 7-10 mm
Colour: Gloden Warranty: one year warranty for any manufacturing defect Daily driver, occasional autocross day or occasional track days, equally at home on street & track. For those seeking a lowered stance as well as enhanced handling & response at a high value. Feature- Rubber top mounts front & rear help to deliver a smooth & forgiving ride for city use at any speed, & rubber joints assist in absorbing hard impacts.- 24 levels of damping rebound adjustment allow you to perfectly dial in your coilover system for both handling & comfort.- Separate height adjustment without sacrifice of damper stroke without removing the coilover out from the car.- Dust boot included to protect damper seal.- Twin-Tube Structure --- For Low Resiliency Securing Sufficient Stroke.- High Tensile performance spring --- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. 6. Plus, the special surface treatment is to improve the durability & performance.- Most pieces in our Coilover systems, including mounts, collars & spring perches, are designed from 6061-T6.- Billet Aluminum resulting in lightweight, durable & rust resistant components.- Steel shock bodies are electroplated with Zinc for anti Anti-corrosion.- Full rebuildable.- Full Length Ride Height Adjustment. Notice- No instruction included; Professional installation alignment suggested.- Please check our store for other auto parts you may be interested in.- Please feel free to contact us for whatever we can help.
...

Application Compatible For BMW 3 (E90) (2004-2011) 316i, 318i, 320i, 323i, 325i, 328i, 330i, 335i, 316d, 318d, 320d, 325d, 330d, 335d. Compatible For BMW 3 Touring (E91) (2004-2012) 316i, 318i, 320i, 323i, 325i, 328i, 330i, 335i, 316d, 320d, 325d, 330d, 335d. Note: 1) This product fit RWD vehicle only!2) We suggest adding washers to avoid the engine bar & drilling the front OE shock top mount upper part a little bigger to a diameter of 12mm. Specification Package included: Complete coilovers for 2 front & 2 reara pair wrench for height adjustment Top mounts: front
- pillow ball top mountsrear
- OE top mounts required Damping: 24 levels rebound damping adjustable Spring rate: front 10 Kg/mmrear 8 Kg/mm Adjustable

Height: Yes, lowering 1" to 3" Shock type: Twin tube Spring Preload: 7-10 mm
Colour: Gold Adjustable camber plate: No Warranty:1 year warranty for any manufacturing defect Feature- Able to lower ride height by 1''-3''; allows user to have a more aggressive stance.- Coilovers are 24-way adjustable. Rebound & Dampening adjustment which allows the user the ability to dial in your coilovers to any driving needs. The user can enjoy a comfortable riding experience in all road conditions.- Twin-Tube Shock design is used for low internal frictional resistance in order to increase efficiency & keep shock temps low.- Height adjustment does not sacrifice damper stroke length.- These coilovers are able to have their height adjusted without being taken out of the car.- High Tensile strength performance spring---Tested under a 600, 000 time continuous compression test, the spring distortion was less than 0.04%. Plus, the special surface treatment improves the durability & performance.- Adjustment tools included in the kit. Notice- Please double confirm before ordering.- No instruction included; Professional installation & alignment suggested.- Please check our store for other auto parts you may be interested in.- For any needs please contact us.




...
