Introduction Ma Xpeeding Rods T6 (also known as SP1) lowering coilover, standard with adjustable rebound damping, separate height adjustment without changing preload, developed damping oil & upgraded racing springs, adjustable camber plate (for some vehicles) & decent outlook offers you more ability to tune your suspension on performance & gives your vehicle more impressive appearance. Besides, all our coilover are assembled in dust-free factory, which turns out good quality & long life. Application Compatible for Mazda Miata MX-5 NA (1.6L, 1.8L) 1989-1997 Compatible for Mazda Miata MX-5 NB (1.6L, 1.8L) 1998- 2005 Compatible for Mazda Miata Base Convertible 2D 1990-1997 Compatible for Mazda Miata Base Convertible 2D 1999-2005 Compatible for Mazda Miata SE Convertible 2D 2000-2003 Compatible for Mazda Miata LE Convertible 2D 1993 Compatible for Mazda Miata M Edition Convertible 2D 1994-1997 Compatible for Mazda Miata STO Convertible 2D 1997 Compatible for Mazda Miata 10th Anniversary Convertible 2D 1999 Compatible for Mazda Miata LS Convertible 2D 2000-2005 Specification Front & Rear top mount pillow ball Damping 24 levels rebound damping adjustable Front spring rate 7 kg/mm (392 lbs/in) Rear spring rate 6 kg/mm (336 lbs/in) Adjustable height Yes lowering 1" to 3" Shock Type twin tube Spring Preload 7-10 mm Color black body with blue spring Feature Lowered height adjustment from 1/2 inch allows a lower centre of gravity & also add a more aggressive stance.A 24 rebound damping adjustment level allows you the ability to perfectly dial in your Coilover setup. You will experience better ride quality in all road conditions. Pillow ball top mount
- It improves the steering feel & response. Full-length dust boot keeps shaft & oil seal from damage. Upgraded damper adjust knob makes damping setting easier. Upgraded valving for a more smooth ride. Twin-Tube structure allows sufficient stroke within the shock absorber. High-Performance Damping Oil--maintains a stable viscosity in a broad temperature range, which sustains smooth stroke & reliable damping force in a variety of circumstances. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%. Decent appearance benefits from CNC machined parts & special surface treatment. Most pieces in our Coilover systems, including mounts, collars & spring perches, are made from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust-resistant components. Complete Suspension Kit of 4 Shock Absorbers 4 Springs for an easy installation. Separate height adjustment does not affect damper stroke & height can be adjusted with coilovers installed on the vehicle. All coilovers were produced & assembled at the dust-free factory which guaranteed the highest quality. Package included Complete coilovers assembly 2 front & 2 rear A pair wrench for height adjustment Dimension Package dimension: 63*51*21 cm Weight: 22kg Warranty: one year warranty for any manufacturing defect

...

Introduction Ma Xpeeding Rods T6 (also known as SP1) lowering coilover, standard with adjustable rebound damping, separate height adjustment without changing preload, developed damping oil & upgraded racing springs, adjustable camber plate（for some vehicles) & decent outlook, offers you more ability to tune your suspension on performance & gives your vehicle more impressive appearance. Besides, all our coilover are assembled in the dust-free factory, which turns out good quality & long life. Application Compatible for LEXUS ES350 2007
- 2009 All Models Compatible for TOYOTA AVALON 2006 Built After 12/05 Production Date Compatible for TOYOTA AVALON 2007
- 2011 All Models Compatible for TOYOTA CAMRY 2007
- 2011 All Models (Notice: WILL NOT FIT HYBRID MODELS) Specification Top mount: Front camber plate: rear pillow ball Damping: 24 levels rebound damping adjustable Spring rate Front: 12 kg/mm (672 lbs/in) Spring rate Rear: 9 kg/mm (504 lbs/in) Adjustable

Height: lowering 1-3 inch Shock type: Twin tube Spring Preload: 7-10 mm
Colour: black body with blue spring Package included Complete coilover assembly kit for front & rear A pair wrench for height adjustment Dimension Package dimension: 62*50*19 Weight: 28960g Feature 1. Lowered height adjustment from 1"
- 3" which allow a lower centre of gravity & also add a more aggressive stance.2. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions.3. Pillow ball top mounts improve the steering feel & response.4. Full-length dust boot keeps shaft & oil seal from damage.5. Upgraded damper adjusts knob makes damping setting easier.6. Upgraded valving for more smooth ride.7. Twin-Tube structure allows sufficient stroke within the shock absorber.8. High-Performance Damping Oil--maintains a stable viscosity in a broad temperature range, which sustains smooth stroke & reliable damping force in a variety of circumstances.9. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%.10. Decent appearance benefits from CNC machined parts & special surface treatment.11. Most pieces in our coilover systems, including mounts, collars & spring perches, are made from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust-resistant components.12. Separate height adjustment does not affect damper stroke & height can be adjusted with coilovers installed on the vehicle.13. All coilovers were produced & assembled at the dust-free factory which guaranteed the highest quality. Warranty: one year warranty for any manufacturing defect







...

Application This product fits RWD vehicles only, not for the M3 model. Compatible for BMW 3 Coupe (E92) (2005-2013) 316i, 318i, 320i, 323i, 325i, 328i, 330i, 335i, 320d, 325d, 330d, 335d Compatible for BMW 3 Convertible (E93) (2006-2013) 318i, 320i, 323i, 325i, 330i, 335i, 320d, 330d, 325d. Note: We suggest adding washers to avoid the engine bar & drilling the front OE shock top mount upper part a little bigger to a diameter of 12mm. Specification Quantity:2 piece front + 2 pieces rear + 2 sway bars + 2 spanners Spring rate Front:6kg/mm (336 lbs/in) Spring rate Rear:10 kg/mm (560 lbs/in) Damper: Non adjustable damper Adjustable
Height: Yes Adjustable camber plate: Yes Warranty:one year warranty for any manufacturing defect Feature-Adjustable ride height-Adjustable pre-load spring tension-Pillow ball top mount -- this design helps combat noise while tuning. It also improves the steering feel & response-Most components are made from 6061 aluminum with T6 for increased hardness -- the advantages include excellent strength, & aluminum helps keep the weight down. -Hi Tensile performance spring
- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. Plus, the special surface treatment is to improve the durability & performance.-All inserts come with fitted rubber boots to protect the damper & keep clean.-A fast & affordable way to easily upgrade your car's appearance.-Easy installation with right tools. Notice-No instruction included; Professional installation alignment suggested.-Please check our store for other auto parts you may be interested in.-Please feel free to contact us for whatever we can help.

...

Introduction MXR-B2 series (also called MXR-SNA) coilovers are designed as an entry level for street use. It features with full length height adjustable & adjustable camber plates (applicable for some vehicles), which offers you a lowered stance, enhanced performance for your daily use vehicle. Application Compatible for BMW 5 series (E6MXR-SNA coilovers are designed as an entry level for street use. It features with full length height adjustable & adjustable camber plates (applicable for some vehicles), which offers you a lowered stance, enhanced performance for your daily use vehicle.0)2004-2010 Sedan AWDmodel:525xi, 528i x Drive, 528xi, 530xi, 535i x Drive, 535xi Will Not Fit Models with Air Suspension Specification Top mounts: front
- pillow ball top mounts rear
- rubber top mounts Damping: not available Spring rate Front: 10 kg/mm (560 lbs/in) Spring rate Rear: 7 kg/mm (392 lbs/in) Spring length Front: 200mm Spring length Rear: 200mm Adjustable

Height: lowering 1-3 inch Coilover overall length Front: 550mm-580mm Coilover overall length Rear: 500mm-575mm Shock type: Twin tube Spring Preload: 7-10 mm
Colour: gold Package includedcomplete coilovers for 2 front & 2 reara pair wrench for height adjustment Dimensionweight: 26500g
Size: 71*51*21 cm Feature 1. Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance 2. Twin-Tube structure allows sufficient stroke within the shock absorber.3. Separate height adjustment does not affect damper stroke.4. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%. Plus, the special surface treatment improves the durability & performance.5. Height Adjustment tools included.6. Pillow ball top mount
- It improves the steering feel & response.7. Most pieces in our coilover systems, including mounts, collars & spring perches, are designed from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust resistant components.8. Steel shock bodies with special surface treatment to improve the durability.9. Full rebuildable. Note Note: The front damper knuckle insert diameter is 49mm or with bushing 55mm. Warranty: one year warranty for any manufacturing defect








...

Introduction A coilover is an automobile suspension device. Thanks to built-in adjustability, coilovers offer the ability to be shortened or lengthened
- lowering or raising the ride height of your vehicle through manual adjustment, without complex electronics or hydraulics. A coilover kit consists of a damper & a shock absorber with a coil spring around it. Maxpeedingrods provides performance aftermarket adjustable coilovers suspension kit compatible for BMW series. You can enjoy a comfortable riding experience in all road conditions. Application Compatible for BMW 3 (E46) 4-door sedan 330i; 325i; 328i; 318d; 320d; 320i, 325i ;330d (02/1998-04/2005) Compatible for BMW 3 2-door Convertible (E46) 330ci; 325ci;323ci; 320cd, 330cd (04/2000-12/2007) Compatible for BMW 3 2-door Coupe (E46) 320ci; 325ci; 330ci;320cd; 330cd; (02/1999-12/2006) Compatible for BMW 3 Touring 5-door wagon/estate (E46) 316i; 325i; 328i; 330i; 323i; 325i; 318d; 320d; 330d; (10/1999-05/2005) Note: Not for Xi/xd 4 wheel drive; Shoter swaybar end link required. Specification Quantity:-2 front+2 rear shocks-2 C- Spanners for adjustment-2 rear Springs+2 front Springs-Front Bump stops & dust covers. Spring Rate: 7 kg/mm (392 lbs/in) ; 7 kg/mm (392 lbs/in) Condition: New Adjustable

Height: YESWarranty: 1 year warranty for any manufacturing defect Features- Adjustable ride height- Adjustable pre-load spring tension- Most components are made from 6061 aluminum with T6 for increased hardness -- the advantages include excellent strength, & aluminum helps keep the weight down.
- Hi Tensile performance spring
- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. Plus, the special surface treatment is to improve the durability & performance.- All inserts come with fitted rubber boots to protect the damper & keep clean.- Improve your handling performance without sacrifice comfortable ride.- A fast & affordable way to easily upgrade your car's appearance.- Easy installation with right tools.- Ideal for any track, drift & fast road & can also be used for daily driving. Notice- No instruction included; Professional installation is highly recommended.- Please check our store for other auto parts you may be interested in.- Please feel free to contact us for whatever we can help.




...

Introduction Ma Xpeeding Rods T6 (also known as SP1) lowering coilover, standard with adjustable rebound damping, separate height adjustment without changing preload, developed damping oil & upgraded racing springs, adjustable camber plate（for some vehicles) & decent outlook, offers you more ability to tune your suspension on performance & gives your vehicle more impressive appearance. Besides, all our Coilover are assembled in the dust-free factory, which turns out good quality & long life. Application Compatible for Honda Civic 1988-1991 EC ED EE EF Rear fork type bracket model only (EC8EC9ED2ED3ED4ED5ED6ED7EE1EE2EE3EE4EE5EE9EF1EF2EF3EF4EF5EF9) Compatible for Honda CR-X 1988-1991 ED EE EF Rear fork type bracket model only (ED8ED9EE6EE8EF6EF7EF8) Compatible for Honda Civic 1992-1995 EG EH EJ Rear fork type bracket model only (EG3EG4EG5EG6EG7EG8EG9EH1EH2EH3EH4EH5EH8EH9EJ1EJ2EJ3) Compatible for Honda CR-X del Sol 1992-1995 EG (EG1) Rear fork type bracket model only Compatible for Honda Civic 1996-2000 EJ EK EM Rear fork type bracket model only (EJ5EJ6EJ7EJ8EJ9EK1EK2EK3EK4EK5EK8EK9EM1) Compatible for Acura Integra 1990 -1993 DA DB Rear fork type bracket model only Compatible for Acura Integra 1994-2001 DC2 DC4 Rear fork type bracket model onlyds strut diameter at the front axle of 55 mm 01/88
- 12/95 Note: This product will not lower the vehicles below: For Honda Civic 1988-1991 EC ED EE EF Rear fork type bracket model For Honda CR-X 1988-1991 ED EE EF Rear fork type bracket model For Acura Integra 1994-2001 DC2 DC4 Rear fork type bracket modelfor some vehicles, you will need sleeves & washers that are already included in our package. Specification Front top mount pillow ball Rear top mount rubber Damping 24 levels rebound damping adjustable Spring rate (Front) 8kg/mm (448 lbs/in) Spring rate (Rear ) 5kg/mm (280 lbs/in)​ Adjustable height Yes lowering 1" to 3" Shock Type Twin tube Spring Preload 7-10 mm Color black body with gold spring Feature 1. Lowered height adjustment from 1"
- 3" which allow a lower center of gravity & also add a more aggressive stance.2. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your Coilover setup. You will experience better ride quality in all road conditions.3. Front pillow ball top mounts improve the steering feel & response.4. Full-length dust boot keeps shaft & oil seal from damage.5. Upgraded damper adjusts knob makes damping setting easier.6. Upgraded valving for a more smooth ride.7. Twin-Tube structure allows sufficient stroke within the shock absorber.8. High-Performance Damping Oil--maintains a stable viscosity in a broad temperature range, which sustains smooth stroke & reliable damping force in a variety of circumstances.9. High Tensile performance spring
- STRESS TESTED OVER 600, 000 times while the spring distortion is less than 0.04%.10. Decent appearance benefits from CNC machined parts & special surface treatment.11. Most pieces in our coilover systems, including mounts, collars & spring perches, are made from 6061-T6 Billet Aluminum resulting in lightweight, durable & rust-resistant components.12. Complete Suspension Kit of 4 Shock Absorbers 4 Springs for an easy installation.13. Separate height adjustment does not affect damper stroke & height can be adjusted with coilovers installed on the vehicle.14. All coilovers were produced & assembled at the dust-free factory which guaranteed the highest quality. Package included Complete coilovers assembly 2 front & 2 rear A pair wrench for height adjustment Dimension Package dimension: 63*51*21 Weight: 22500g Note For some vehicles, you will need sleeves & washers that are already included in our package. Warranty: one year warranty for any manufacturing defect


...

Introduction Ma Xpeedingrods is a leading manufacturer of high-quality Auto parts since 2006. Ma Xpeedingrods coilovers are designed & developed for all motoring enthusiasts wanting excellent handling without sacrificing comfort. This suspension system features 24 levels of damping force adjustability & full length adjustment to meet every driver's handling desires. Pillow ball mounts & adjustable camber plates are included for front & rear on most kits to increase steering response, while aluminium upper mounts with hardened rubber bushings are used on some applications for noise reduction. This suspension system is ideal for daily driving & occasional track use. Application Compatible for Infiniti M35x 06-10 AWDCompatible for Infiniti M45x 06-10 AWDCompatible for Infiniti G35x 03-08 AWDCompatible for Infiniti G37x 08-13 AWDNote: Will not fit RWD model; Rear true coilover

Specification- Top mounts: standard rubber top mount front & rear- Damping: 24 levels rebound damping adjustable- Spring rate Front: 12 kg/mm (672 lbs/in)- Spring rate Rear: 10 kg/mm (560 lbs/in)- Spring length Front: 160mm- Spring length Rear: 200mm- Adjustable

Height: lowering 1-3 inch- Coilover overall length Front: 340mm-410mm- Coilover overall length Rear: 500mm-590mm-Shock type: Twin tube-
Colour: black body with blue spring- Brand: Ma Xpeedingrods- Condition: 100% Brand New- Warranty: 1 Year Package included 1 x Set of Coilover Spring Kit (2 Front + 2 Rear)1 x Pair of wrenches for height adjustment 1 x Installation Instructions Features 1. Lowered height adjustment from 1"
- 3" which allow lower center of gravity & also add a more aggressive stance 2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent 3. Adjustable Camber Plate & Pillow ball top mount for sharpening steering response. (for some models) 4. 24 levels of adjustable damper -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff. 5. CNC machined Aluminum top mounts & lockers--
- excellent strength, & save weight 6. Heavy Duty Steel Lower Mounts--- Highly Durable Reliable 7. Upgraded spring --- more than 600, 000 times continuously test to assure it's high tensile strength. 8. All inserts come with fitted long rubber boots--- To protect the damper more well & be durable. 9. With better damping setting, you will get better performance & comfort at the same time. 10. Twin-Tube structure ---provides excellent handling control characteristics for most driving conditions 11. Corrosion Finish
- Anodized Aluminum & Powder Coated Carbon Steel Parts 12. Test for the best---Every parts were tested on our professional machine before assembled & tested by our professional racers on road. 13. Clean room assembled---maintain higher level of accuracy & reliability. 14. Upgraded damper oil---make damping more stable & smooth in wide temperature range.







...

Application Compatible for Mitsubishi Eclipse (3rd-Gen) D53A/D52A 2000-2005 Specification Top mounts: pillow ball top mount with camber plate front, standard rubber top mount rear. Quantity:complete coilovers 2 front & 2 rear, a pair wrench for height adjustment Spring rate Front: 10 kg/mm (560 lbs/in) Spring rate Rear: 7 kg/mm (392 lbs/in) Damping: 24 levels rebound damping adjustable Adjustable

Height: Yes lowering 1" to 3" Shock type: Twin tube Spring Preload: 7-10 mm
Colour: Golden Warranty: 1 year warranty for any manufacturing defect Feature- Adjustable ride height.- Adjustable pre-load spring tension.- 24 levels of adjustable damper -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff.- Most components are made from 6061 aluminum with T6 for increased hardness -- the advantages include excellent strength, & aluminum helps keep the weight down.
- Hi Tensile performance spring
- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. Plus, the special surface treatment is to improve the durability & performance.- All inserts come with fitted rubber boots to protect the damper & keep clean.- A fast & affordable way to easily upgrade your car's appearance.- Easy installation with right tools.- Ideal for any track, drift & fast road & can also be used for daily driving. Note No instruction included; Professional installation & alignment suggested. Please check our store for other auto parts you may be interested in. Please feel free to contact us for whatever we can help.




...

Introduction Ma Xpeeding Rods T6 (also known as SP1) lowering coilover, standard with adjustable rebound damping, separate height adjustment without changing preload, developed damping oil & upgraded racing springs, adjustable camber plate（for some vehicles) & decent outlook offers you more ability to tune your suspension on performance & gives your vehicle a more impressive appearance. Besides, all our Coilover are assembled in the dust-free factory, which turns out good quality & long life. Application Compatible for Honda Accord VII 4-door sedan CM4/CM5/CM6 2003-2007 Compatible for Honda Accord VII 2-door coupe CM7/CM8 2003-2007 Compatible for Honda Inspire 2003-2007 （ Japan market only） Specification Top mounts: Front pillow ball top mounts Damping: 24 levels rebound damping adjustable Adjustable

Height: Yes, lowering 1" to 3" Adjustable camber plate: No Spring rate Front: 10 kg/mm (560 lbs/in) Spring rate Rear: 6 kg/mm (336 lbs/in) Shock Type: Twin tube Spring Preload: 7-10 mm
Colour: Black body with orange spring Package includedproduct included: complete coilovers 2 front & 2 rear Dimension
Size: 71*51*21 cm Weight: 27.08kg Feature Lowered height adjustment from 1"
- 3" allows a lower centre of gravity & also add a more aggressive stance. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent. Front pillow ball top mounts improve the steering feel & response.24 levels of adjustable damper -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff.CNC machined Aluminum top mounts & lockers--
- excellent strength, & save weight. Heavy Duty Steel Lower Mounts--- Highly Durable Reliable. Upgraded spring --- more than 600, 000 times continuously test to assure its high tensile strength. All inserts come with fitted long rubber boots--- To protect the damper better & be durable. With a better damping setting, you will get better performance & comfort at the same time. Twin-Tube structure ---provides excellent handling control characteristics for most driving conditions. Corrosion Finish
- Anodized Aluminum & Powder Coated Carbon Steel Parts. Cleanroom assembled---maintain a higher level of accuracy & reliability. Upgraded damper oil---make damping more stable & smooth in a wide temperature range. Warranty: one year warranty for any manufacturing defect






...

Introduction A coilover is an automobile suspension device. Thanks to built-in adjustability, coilovers offer the ability to be shortened or lengthened
- lowering or raising the ride height of your vehicle through manual adjustment, without complex electronics or hydraulics. A coilover kit consists of a damper & a shock absorber with a coil spring around it. Maxpeedingrods provides performance aftermarket height adjustable coilovers suspension kit compatible for Lexus series. You can enjoy a comfortable riding experience in all road conditions. Application Compatible for Lexus LS460/460L (USF40, USF41)2007-2016 RWDNote: Will not Fit AWD or Model with air suspension Specification Quantity: 2 pieces front + 2 pieces rear, Spanner as shown in the picture Spring rate Front: 12 kg/mm (672 lbs/in) Spring rate Rear: 8 kg/mm (448 lbs/in) Adjustable Damper: Non adjustable Damper Adjustable

Height: Yes Adjustable camber plate: Yes
Colour: Golden Warranty: one year warranty for any manufacturing defect Feature- Adjustable ride height.- Adjustable pre-load spring tension.- Pillow ball top mount -- this design helps combat noise while tuning. It also improves the steering feel & response.- Most components are made from 6061 aluminum with T6 for increased hardness -- the advantages include excellent strength, & aluminum helps keep the weight down.- Hi Tensile performance spring
- Under 600, 000 times continuously test, the spring distortion is less than 0.04%. Plus, the special surface treatment is to improve the durability & performance.
- All inserts come with fitted rubber boots to protect the damper & keep clean.- Improve your handling performance without sacrifice comfortable ride.- A fast & affordable way to easily upgrade your car's appearance.- Easy installation with right tools.- Ideal for any track, drift & fast road & can also be used for daily driving. Note- No instruction included; Professional installation is highly recommended.- Please check our store for other auto parts you may be interested in.- Please feel free to contact us for whatever we can help.





...
